Öhlins for Yamaha MT-09

These Öhlins front and rear suspension upgrades will transform the feeling of your Yamaha MT-09 with superior chassis performance, traction and stability.

Öhlins developed a high quality front fork cartridge kit and feature-packed rear shocks to upgrade Yamaha’s MT-09 and the results are awesome! Are you ready to transform your Yamaha into an urban warrior? Then fit both front and rear upgrades and experience full transformation!

Cartridge kit NIX 30

Öhlins part no. FKS 504
MT-09 (2014-2020)
MT-09 SP (2018-2020)

Öhlins part no. FKS 518
MT-09 (2021-2022)

Öhlins part no. FKS 519
MT-09 SP (2021-2022)

Using the well proven NIX 30 technology from the Road & Track range, Öhlins developed this excellent cartridge kit for the Yamaha MT-09.

Now, you can fully personalise your front suspension using the kit’s stylish replacement top caps, which have rebound damping adjustment on one leg, compression damping on the other and adjustable spring preloads on both.

The Öhlins front fork cartridge kit fits easily inside the standard fork legs and improves overall chassis performance and “feeling” with enhanced cornering and increased front-end stability, especially when braking.

Rear shock S46DR1

Öhlins part no. YA 335
MT-09 (2014-2020)

Öhlins part no. YA 570
MT-09 (2021-2022)

The Öhlins S46DR1 rear shock is from the STX46 range and uses a Monotube, high pressure gas design with internal gas reservoir.

Designed for Yamaha MT-09 this high quality shock has adjustable rebound damping and spring preload. The shock improves overall rider “feeling” with enhanced traction and stability.

Rear shock S46DR1S

Öhlins part no. YA 534
MT-09 (2014-2020)

The Öhlins S46DR1S rear shock (Öhlins part no. YA 534) is also from the STX46 range and uses a Monotube, high pressure gas design with internal reservoir.

Designed for Yamaha MT-09 (2014-2020) this high quality shock has adjustable rebound damping with the additional feature of a handy hydraulic spring preload adjuster. The shock improves overall rider “feeling” with enhanced traction and stability.

Rear shock S46HR1C1S

Öhlins part no. YA 535
MT-09 (2014-2020)

Öhlins part no. YA 569
MT-09 (2021-2022)

The Öhlins S46HR1C1S rear shock is also from the STX46 range and uses a Monotube, high pressure gas design with external reservoir for typical Öhlins performance and durability.

Designed for Yamaha MT-09 (models listed below) this high quality shock has adjustable compression and rebound damping in addition to a very practical remote hydraulic spring preload adjuster.

The shock provides the most adjustability in the range, improving overall rider “feeling” with enhanced traction and stability.

Rear shock S46HR1C1S Blackline

Öhlins part no. YA 588
MT-09 (2015-2020)

Öhlins part no. YA 580
MT-09 (2021-2023)

Öhlins S46HR1C1S Blackline rear shock for Yamaha MT-09 fully adjustable in compression and rebound damping and spring preload and featuring a hose-mounted reservoir and easy-to-use remote spring preload adjuster

This Öhlins S46HR1C1S rear shock is built to the same high specification, but beautifully styled from the Blackline range.

Designed for Yamaha MT-09 (years and part numbers above) this high quality shock also has adjustable compression and rebound damping in addition to a very practical remote hydraulic spring preload adjuster.
